The standard specifications for the Cincinnati 90CBII-10 are highly consistent across mid-to-late 1990s models:
Bending Capacity: 90 Tons
Overall Bed & Ram Length: 12 feet (144 inches)
Distance Between Housings: 10 feet 6-1/4 inches (126.25 inches)
Maximum Stroke: 8 inches
Open Height (Daylight): 15 inches
Closed Height: 7 inches
Throat Depth: 7 inches
Ram Speeds:
Rapid Approach: 260 IPM (Inches Per Minute)
Forming/Pressing: Variable from 10 to 80 IPM
Return Speed: 280 IPM
Main Motor: 15 HP
Approximate Machine Weight: 20,000 lbs
Approximate Shipping Dimensions: 13 L x 710" W x 94" H
Core Features & Controls
Hydraulic Precision: Employs dual clevis-mounted, self-aligning hydraulic cylinders combined with linear transducers to constantly monitor and correct bed-to-ram parallel parallelism.
Safety & Operation: Includes dual palm-button safety controls alongside heavy-duty cast iron electric foot pedals for versatile operation.
To view more information on the 90 TON X 12 CINCINNATI 90CBII HYDRAULIC PRESS BRAKE,MANUFACTURED:2001 OUR STOCK NUMBER: 13006, including reviews, brand information, photos, videos, and more,
