Working Length: 3100 mm (122")
Max. Press Force: 1600 kN (176 US Tons)
Standard Stroke: 7.9"
Max. Stroke: 300 mm (11.81")
Open Height: 18.9"
Distance between Side Frames: 96.5"
Throat: 15.8"
Rapid Approach: 425 in/min
Working Speed: 1-13 mm/s
Return Speed: 425 in/min
Backgauge
X-axis Travel: 23.6"
X-axis Speed: 1417.3 in/min
X-axis Position Accuracy: 0.002"
R-axis Travel: 5.9"
R-axis Speed: 472.4 in/min
R-axis Position Accuracy: 0.002"
Z-axis Travel: 72"
Z-axis Speed: 2362.2 in/min
Max. Y-Approach Speed: 330.7 in/min
Max Y-Working Speed: 23.6 in/min
Y-Position Accuracy: 0.0004"
Electric values
Power of Main Motor: 18.5 kW
Total Connected Load: 30 kW
Operating Voltage: 3PH 480V
Frequency: 60Hz
Control voltage V DC: 24
Nominal Current Fuse A: 63
Dimensions
Length: 154"
Width: 74"
Height: 107"
Weight: 25,353 lbs
Click on links below for videos under power:
To view more information on the 160 TON X 10 BYSTRONIC XACT SMART 160/3100 CNC HYDRAULIC PRESS BRAKE,MFG:2016 OUR STOCK NUMBER: 12956, including reviews, brand information, photos, videos, and more,
